Eacam A1 Mini Multimeter LCD Digital Tester Voltage Detector 2000 Counts DC/AC Voltage Frequency Resistance NCV Continuity Live Wire Neutral Wire Check True RMS Meter

This is a mini multimeter, which has automatic identification design. Connect the test leads in parallel to the circuit, power supply, tested resistor. The meter automatically identify whether it is AC voltage, DC voltage or resistance, and shows the frequency on the screen. Note: 1. Do not input voltages higher than 500V, showing higher voltage are possible, but it may damage the meter. 2. When measuring high voltage, be careful to avoid electric shock. 3. Disconnect the test leads from the circuit when completed measurement. 4. Due to different light conditions and different monitors, item color displayed in photos may be showing slightly different from real object. Specifications: Model: A1 Color: Black Shell Material: ABS Display: LCD Maximum Display Value: 2000 Digits Polarity Indication: Self-indicating, '-' means negative polarity Over-range Display: 'OL' or '-OL' Sampling Time: The meter figures show about 0.4 seconds Automatic Power Off Time: 5 minutes Battery Low Voltage Indication: LCD display symbol Operational Temperature: 0~40℃ / 32~104℉ Storage Temperature: -10~60℃ / -4~140 ℉ Operating Altitude: ≤ 2000m Battery: 1.5V AAA x 2 ( Not Included ) Automatic Measuring Range: YES Full Measuring Range Overload Protection: YES Flashlight: YES V-Alert (NCV): YES Live / Neutral Wire Check: YES Breakpoint Locate: YES Automatic Identification: YES Item Size: 12.7*4.2*2.5cm / 5.00*1.65*0.98in (L*W*H) Packing Size: 16.5*7.3*3.8cm / 6.50*2.87*1.50in (L*W*H) Net Weight: 67g / 2.36oz ( without battery） Gross Weight: 159g / 5.54oz Package List: 1 * Multimeter ( Without Battery ) 2 * Test Lead ( Red & Black ) 1 * Screwdriver 1 * Instruction Manual ( Chinese & English )
